This fire-resistant glass is manufactured by applying a special fire-retardant solution onto the surface of float glass, followed by tempering. Tempering enhances the glass surface’s resistance to thermal shock and mechanical strength, while the fire-retardant coating reflects heat during a fire and forms a protective layer on the surface, delaying glass breakage at high temperatures.
Monolithic Structure: Thickness ranges from 5 to 19 mm.
Fire-rated partitions and façades with low thermal insulation requirements
| Thickness（mm） | Fire Performance Rating | Fire Resistance Rating(min) | Weight(KG) | Maximum Service Temperature(℃) |
| 5 | E | 30/60/90 | 12.5 | 1000 |
| 6 | E | 30/60/90 | 15 | 1000 |
| 8 | E | 30/60/90 | 20 | 1000 |
| 10 | E | 30/60/90 | 25 | 1000 |
| 12 | E | 30/60/90 | 30 | 1000 |
| 15 | E | 30/60/90 | 37.5 | 1000 |
| 19 | E | 30/60 | 47.5 | 1000 |
